Marshall Compactor

Contact

Product code: 5ZQASYPOJI

Category: Asphalt Testing

Marshall Compactor – QualiAMC is used to prepare asphalt mixture specimens using the standard compaction method. It…

Marshall Compactor – QualiAMC is used to prepare asphalt mixture specimens using the standard compaction method. It enables testing of the physical and mechanical properties of asphalt mixtures in laboratory settings.

Marshall Compactor – QualiAMC Technical Specifications

Specification	Details
Power supply	Three-phase three-wire 380V, 0.3KW
Drop height	457mm ±1.5mm
Hammer weight	10210g ±10g / 4536g ±9g
Compaction speed	55 ±5 times/min
Preset compaction times	Maximum 9999 times
Specimen size	Φ152.4mm (±0.2mm) × 115mm / Φ101.6mm (±0.2mm) × 63.5mm
The Marshall compactor QualiAMC supports both φ152.4mm(±0.2mm)×115mm and φ101.6mm (±0.2mm)×63.5mm cylindrical specimens used in Marshall test and indirect tensile test. QualiAMC has two sizes of hammer weight.
Controller form	Digital display Phase sequence protection: Not available Hammer lifting device: Manual lever convenient hammer lifting device, electric hammer lifting device and die ring automatic pressing device.

Marshall Compactor – QualiAMC

A precision-engineered machine designed for asphalt mixture specimen preparation in compliance with standard Marshall compactor test protocols. Ideal for laboratory settings, it facilitates accurate compaction of specimens for evaluating the physical and mechanical properties of asphalt mixtures.

This compact and efficient solution features adjustable number of blows and a reliable automatic counter, ensuring accurate control during testing. Its manual lever hammer lifting device provides convenience, with optional upgrades to electric operation for enhanced efficiency.

Whether configured for manual or automatic operation, the Marshall compactor machine is equipped with advanced features to maintain consistent performance. Its robust design and adherence to strict Marshall compactor specifications make it a dependable choice for asphalt testing laboratories globally.

Marshall Compactor

It is suitable for forming cylindrical specimens of Φ152.4mm (±0.2mm) × 115mm and Φ101.6mm (±0.2mm) × 63.5mm, used in Marshall tests and indirect tensile tests. The QualiAMC features a manual lever hammer lifting device.
