Asphalt Density Gauge – Non-Nuclear

Contact

Product code: 4IULT9PW7J

Category: Asphalt Testing

Asphalt Density Gauge – Non-Nuclear QualiADG delivers precise measurements of asphalt density, moisture content, and…

The Asphalt Density Gauge – Non-Nuclear QualiADG offers advanced, secure, and cost-effective density measurement for asphalt concrete. Using innovative non-nuclear technology, it eliminates the need for licenses or storage concerns, making it an efficient and user-friendly solution for asphalt testing.

Equipped with a full-color VGA display and user-friendly graphical interface, this non-nuclear asphalt density gauge ensures easy operation and fast results, delivering precise readings in less than five seconds. Its rugged lightweight design and Microsoft Windows CE operating system enhance portability and reliability in demanding conditions.

The gauge includes a data management screen for seamless access to stored data, which can be downloaded via a USB drive. Features like software upgrades and an LED backlighting display ensure up-to-date functionality and excellent visibility in various environments.

Asphalt Density Gauge – Non-Nuclear QualiADG Technical Specifications

Specification	Details
Operational Specifications
Modes	Single: Reading time less than five (5) seconds. Stores data. Average: Averages five (5) readings and stores data, including date and time. Stores thousands of records. Continuous: Instantaneous density readings.
Functions	Density, % Compaction Porosity % Integrated Temperature Sensing: Real-time temperature display (0℃ to 350℃)
Calibration Modes	Normal: Correlation offset to cores.
Measurement Specifications
Sensing Area	11 in. (27.9 cm) diameter base, allows optimum measurement on fine and coarse material types.
Measurement Depth	110mm
Measurement Display	Density, % Compaction, Surface Temperature, Mix Name & Project Name
Mechanical Specifications
Shipping Weight w/Case	9.00kg
Shipping Dimensions	490 × 220 × 390 mm
Electrical Specifications
Microprocessor Controlled
Battery	2.5 Amp-hr NiMH, 12V
Recharge Time	4 hours
Battery Charger	12V Universal AC charger
Computer Ports	1 USB Port

Asphalt Density Gauge – Non-Nuclear QualiADG Operational Features

Status Bar: Displays GPS status, data save status, battery voltage, low battery alerts, and date and time.
Project Details: Stores up to 10 projects, including relevant details.
Mix Details: Stores up to 20 mixes, including information such as MTD, mix name, stone size, depth, offset, and operator name.
Data Logging: When enabled, stores all measurements taken in single or average modes. (Status bar icon)
Reports: Easily download data to be imported into Excel.
GPS Control: When activated, displays latitude and longitude, the number of satellites the gauge is connected to, as well as UTC date and time, available in UTM format. GPS info is stored with each measurement when data save and GPS feature are enabled. (Status bar icon)
Update Software: One-touch upload of new software via USB memory stick.
Data Management: Quickly access, download, or delete project data.
Set Time & Date: Quick time and date setup, with MM/DD, D/YY, and DD/MM/YY formats.
Units: Interchangeable settings for density (kg/m³, lb/ft³), temperature (°C, °F), depth (in, mm), and stone size (in, mm).
Enhanced Customer Support: Diagnostic screen for factory support assistance.
User Programmable Target Density: Used for calculating % compaction.

Asphalt Density Gauge – Non-Nuclear QualiADG

Delivers precise measurements of asphalt density, moisture content, and percent compaction, commonly used for roads and foundations. Utilizing non-nuclear technology, it offers a cost-effective, efficient, and secure solution for asphalt testing.

Full-color, touch-screen user interface for ease of use.
Status bar displays GPS status, data save status, battery voltage, low battery alerts, date, and time.
Enhanced data management allows quick access, download, or deletion of project data. Files can be downloaded via USB.
Provides fast, reliable, and accurate density and compaction tests with repeatable real-time readings.
User-friendly and cost-effective, requiring no additional calibration.
On-site testing delivers precise results in just three seconds, offering superior accuracy and stability.
Non-nuclear technology eliminates the need for badges, licenses, or storage and transport concerns.
