Name: Viskomat XL Rheometer for Fresh Concrete and Mortar
SKU: M6NWYDZ5AH
Availability: InStock
Rating: 5 (1 reviews)

Viskomat XL Rheometer for Fresh Concrete and Mortar

Contact

Product code: M6NWYDZ5AH

The Viskomat XL Rheometer for Fresh Concrete and Mortar is a versatile tool designed for assessing the workability and…

Viskomat XL Rheometer for Fresh Concrete and Mortar Technical specifications

Velocity controlled	0.0001 … 80 rpm
Torque measurement ranges	0 … 3,000 Nmm / 0 … 10,000 Nmm
Resolution	0.5 Nmm / 2 Nmm
Sampling rate	0.005 s … 10 min
Sample volume	3,000 ml
Shear stress controlled drive	Torque resolution: 0.001 Nm / angle resolution: 0.01°
Oscillation mode	Max. Amplitude: 30 °/ Max. Frequency: 4 Hz
Power supply	110 V ..240 V / 50 Hz... 60 Hz
Net weight	Approx. 50 kg

Order information:

Items no.	Description	Items no.	Description Probes
VX0001	Rheometer Viskomat XL	VX0013	Mortar probe
VX0006	Shear stress controlled Drive	VX0011	Cement probe
VX0030	Oscillation mode	VX0004	Vane probe
VX0009	Outer container for temperature control	VX0005	Basket for the vane probe
V0019	Chiller, closed loop system	VX0007	Sphere probe

Viskomat XL Rheometer for Fresh Concrete and Mortar Features

Sturdy equipment suitable for both laboratory and industrial settings

Customizable measurement profiles

Includes a network interface for easy integration into an intranet or lab network

No need for specialized PCs or software

Optional features include a shear stress-controlled drive and oscillation mode

Ideal for research purposes and quality control

Viskomat XL Rheometer for Fresh Concrete and Mortar

Qualitest-Schleibinger offers a flexible rotational viscometer used to measure the workability of construction materials like cement paste, mortar, plaster, SCC, or UHPC, handling particles up to 16 mm in size. It's perfect for both research and development and quality control purposes.

With the Viskomat XL rheometer, you can gather the following data:
