Features

• Accurate measurement of the specific gravity of rubber, plastics, and much more
• High stability weighing sensor
• Auto-weighing function
• Powder Density, which improves working efficiency and accuracy
• Simple & convenient operation by placing the sample on top of the container, and then in the water container

Advantages

• Measuring capacity up to 3kg
• Compact body and accurate density measurement for solid and liquid samples.
• Only 10 seconds to measure density and volume, just putting the sample into the water.
• Powder density measurement with a resolution of 0.001g/㎤ and a reference value of 0.0001g/㎤.

Densimeter – Specific Gravity Tester Overview

• Supports quality control and new product development
• Utilized in rubber, plastic, and various composite material industries
• Over 17,000 units supplied worldwide

Density Measurement

• Effective for checking material types and mixing ratios
• Evaluates quality and compares products
• Simple testing procedures and measurement principles

Measurement Procedures

• Upper Sensor Unit: Reacts to the sensor
• Tray in Water: Suspended from the upper sensor unit
• Water Tank: No reaction to the sensor
• Shortest measurement time: 10 seconds
  1. Place the sample on the tray to measure weight in the air.
  2. Submerge the sample into water to measure weight in water.
  3. View the density result (Model EW-300SG).

A special GK-Series of these densimeters are available for density and carat measurement of precious metals such as gold, silver and platinum.
